ERROR
CODE
12 PS1 error
The input is not seeing a closed connection from the external pressure switch to FSC. If this
feature is unused, program ‘PI2’ to another option or insert a jumper from FSC to PS1 pro-
grammable input. If the feature is being utilized, verify that valve and pressure switch are
functioning appropriately.
13 SCR short
Check SCR, weld transformer wiring, and control wiring.
14 Second Stage error
Control has timed out waiting for 2nd Stage input. Verify connection and signal to 2nd Stage
programmable input.
15 TT1 Error
The input is not seeing a closed signal from the Transformer Thermal Limit Switch. If this fea-
ture is unused, program TT1 programmable input to another option. If the feature is being uti-
lized, verify that the transformer is not overheating.
16 Interlock Error
Control has timed out waiting for Interlock input. If this feature is unused, program Interlock
programmable input to another option. If the feature is being utilized, verify that the external
weld interlock is functioning appropriately.
19 High Current 1
The control measured a higher current for Weld1 than the programmed upper limit. Verify that
the impedances are normal and/or consider changing the programmed value under the ‘Edit
Schedule’ menu.
20 Low Current 1
The control measured a lower current for Weld1 than the programmed lower limit. Verify that
the impedances are normal and/or consider changing the programmed value under the ‘Edit
Schedule’ menu.
21 High Current 2
The control measured a higher current for Weld2 than the programmed upper limit. Verify that
the impedances are normal and/or consider changing the programmed value under the ‘Edit
Schedule’ menu.
22 Low Current 2
The control measured a lower current for Weld2 than the programmed lower limit. Verify that
the impedances are normal and/or consider changing the programmed value under the ‘Edit
Schedule’ menu.
23 High Voltage
The AC line voltage is measured above the programmed upper limit under the “voltage moni-
tor” parameter. Check the AC line voltage and/or adjust the parameter under the ‘Config’
menu.
24 Low Voltage
The AC line voltage is measured below the programmed lower limit under the “voltage moni-
tor” parameter. Check the AC line voltage and/or adjust the parameter under the ‘Config’
menu.
25 Counter end
Reset the counter. If this feature is not being utilized, consider disabling it under the ‘Edit
Counter’ menu.
26 Stepper end
Reset Stepper. If this feature is not being utilized, consider disabling it under the ‘Stepper’
menu.
6.1 Error Codes
