15
1
/4"
(386 mm)
19"
(483 mm)
17
1
/2"
(444 mm)
19
1
/2"
(496 mm)
17
7
/8"
(455 mm)
34
1
/8"
(868 mm)
19
3
/4"
(503 mm)
24
7
/8"
(632 mm)
ROOMAIR
FANON/OFF
ON/OFF
FEEDRATE
TRIM
COMBUSTION
BLOWERTRIM
HEATLEVEL
AUTO/OFF
HIGH/LOW
MANUAL
AUGER
MODE
6
Specifications
DIMENSIONS AND SPECIFICATIONS:
Figure 1: Dimensions of Mini.
Weight (with full hopper): 238 lb (108 Kg)
Hopper Capacity: up to 48 lb (21.8 Kg)
Voltage: 110 - 120 V
Max Current: 4.1 Amps
Consumption on High: 3.1 lb/hr (1.4 Kg/hr)*
Consumption on Low: 1.3 lb/hr (0.6 Kg/hr)*
(Note: Consumption will vary with the type of
fuel used.)
