10
Eco dMEV+ Centrifugal Extract Fan
The Eco dMEV+ extract fan range is
manufactured to the highest stan-
dards of production and quality as
laid down by the international Quality
Standard ISO 9001. All components
have been checked and every one of
the fi nal products will have been in-
dividually tested at the end of the ma-
nufacturing process.
On receipt of the product we recom-
mend that you to check the following:
1. That it is the correct model.
2. That the details on the rating label
are those you require: voltage, fre-
quency...
The installation must be carried out in
accordance with Building Regulations
and the current I.E.E. wiring regu-
lations (BS7671) or the equivalent
standards in force in your country.
This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physi-
cal, sensory or mental
capabilities or lack of
experience and knowl-
edge if they have been
given supervision or
instruction concerning
use of the appliance
in a safe way and un-
derstand the hazards
involved. Children
shall not play with the
appliance. Cleaning
and user maintenance
shall not be made by
children without su-
pervision.
INSTALLATION
IMPORTANT: Before installing and
wiring the unit, ensure that the mains
supply is disconnected.
Fig. 1b:
1. Front grille
2. Protection cover
3. Support
4. Connection terminals
5. Cable entry
6. Dip switches
7. Setting tool
8. Air fi lter
The Eco dMEV+ is suitable for wall or
ceiling mounting and can either ex-
tract directly to the outside or through
a ducted system (see Fig. 2).
Make a Ø105 mm hole in the wall or
ceiling.
If the unit is to be installed with duct-
ing, use a standard Ø100 mm duct.
