AFTER INSTALLATION THE END USER SHOULD
KEEP THIS GUIDE FOR FUTURE REFERENCE
DO NOT
THROW AWAY
20
a
Diffuser installed without blanking plates fitted.
b
Power usage shown with heater function disabled.
c
Energy cost on electricity cost of £0.15 per kWh.
d
Figures calculated at incoming air temperature below 19 degrees C.
House size
setting
Max air flow rate
(l/s)
a
Power usage
(Watts)
b
Total energy cost
per year (£)
c d
1. 28 2.7 £3.55
2. 38 3.8 £4.99
3. 46 5.4 £7.10
4. 56 8.3 £10.91
Performance Figures - PIV INLINE
House size
setting
Max air flow rate
(l/s)
a
Power usage
(Watts)
b
Total energy cost
per year (£)
c d
1. 22 3 £4.34
2. 29 4 £6.04
3. 35 5 £9.33
4. 43 8 £14.59
Performance Figures - MIV INLINE
