3.18
Charger LED
The colour of the LED should be
interpreted as follows:
EO Genius & EO Hub Installation Guide
© EO Charging 2021 27
3.0
STATE LED COLOUR NOTES
Power OFF Not illuminated No power is available
Power ON LED solid RED Initialising
Power ON LED pulses BLUE Unit has started up successfully and is ready to charge
STATE LED COLOUR NOTES
No cable inserted LED pulses BLUE Ready to charge
Cable inserted
LED pulses GREEN
LED solid GREEN
Charging station is communicating with the vehicle and
trying to start a charging session
A charging session has started successfully
Cable removed LED pulses BLUE Ready to charge
Paused LED solid YELLOW The unit has been paused by the EO Hub
Power up
Normal operation
3.17
Powering up the EO Genius
On powering up the charge
stations the LED’s will rstly
ash red. Then will settle to
pulsing blue (normal state).
If a red LED is shown after six
blue pulses, this would signify
a bad serial line connection
meaning the charger cannot
communicate with the EO Hub.
Check all serial line connections
including connectors and re-
check.
Figure 16
Figure 17
