Connector Left or Right CT Connection & Cable Colour
CT1 (Left) Left Load Management - White
CT1 (Left) Right Load Management - Black
CT2 Left DO NOT USE
CT2 Right DO NOT USE
CT3 Left Solar - White
CT3 Right Solar - Black
3.08
Connect the other end of the CT Clamp to the EO Mini Base.
