7.2.3 NIR
Table 73: full description of the new NIR slit mask
Position
Size
Physcal size (”)
Purpose
1
0.5”  pinhole
0.490
CAL
2
5”11” slit
5.004
SCI / CAL
3
0.9”11” slit
0.917
SCI / CAL
4
1.0”12.6” slit
0.991
With IFU only
5
1.2”11” slit
1.191
SCI / CAL
6
tilted slit
TECH (focus)
7
0.6”x11” JH
0.623
SCI / CAL
8
Blind
9
0.9”x11” JH
0.904
SCI / CAL
10
0.4”11” slit
0.386
SCI/CAL
11
Raw of 9 pinholes of
0.5”  spaced at 1.4”
0.501
CAL
12
0.6”11” slit
0.612
SCI/CAL
Table 74: full description of the old NIR slit mask
Position
Size
Physcal size (µm)
Purpose
1
0.5”  pinhole
270  hole
CAL
2
5”11” slit
26955683
CAL
3
0.9”11” slit
4855683
SCI / CAL
4
1.0”12.6” slit
5446510
With IFU only
5
1.2”11” slit
6475683
SCI / CAL
6
tilted slit
TECH (focus)
7
1.5”11” slit
8
Blind
9
0.4”  pinhole
216  hole
TECH
10
0.4”11” slit
2165683
SCI/CAL
11
Raw of 9 pinholes of 0.5”
 spaced at 1.4”
270  holes spaced by
723
CAL
12
0.6”11” slit
3235683
SCI/CAL
