Replacing the Battery
• Remove the battery compartment by lifting up on the locking cam lever and
carefully sliding the battery compartment away and up from the sight housing
(
FIGURE 2).
• After the battery compartment is removed, slide the batteries out and replace
them with a fresh set. The labels on the bottom of battery compartment show the
correct battery orientation.
• Always make sure the gasket is free of dirt before the battery compartment is
reinstalled or the seal may be compromised.
• To reinstall the battery compartment, point the sight towards the ground and slide
battery compartment onto base.
• Make sure there is enough clearance between the contact and the batteries to
avoid bending the contacts.
• Hold the battery compartment down firmly against the base and close the
locking cam.
• Before you push down on cam lever, make sure the battery compartment sits all
the way down and is parallel to the base.
• Verify correct battery installation immediately by turning on the sight and checking
if the holographic reticle appears.
• If the batteries are left in the sight backwards, they will be drained of their power.
Locking
Cam Lever
FIGURE 2
