ep EPL151 - Dimensions and specifications

REV. 09/2020
E2
3.2 Tyre size, driving
wheels(diameter×width)
mm Ф210x70 Ф210x70
3.3 Tyre size, loading
wheels(diameter×width)
mm Ф80x60(
Ф74x88)
Ф80x60(
Ф74x88)
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф74x30 Ф74x30
3.5 Wheels, number driving, caster/
loading (x=drive wheels)
mm 1x,2/4(1x,2/2) 1x,2/4(1x,2/2)
3.6 Track width, front,driving side b10 mm 450 450
3.7 Track width,rear,loading side b11 mm 390/(535) 390/(535)
Dimensions
4.4 Lift height h3 mm 115 115
4.9 Height drawbar in driving position
min./max.
h14 mm 700/1260 700/1260
4.15 Lowered height h13 mm 80 80
4.19 Overall length l1 mm 1550 1550
4.20 Length to face of forks l2 mm 400 400
4.21 Overall width b1/ b2 mm 610(695) 610(695)
4.22 Fork dimensions s/ e/ l mm 50x150x1150 50x150x1150
4.25 Distance between fork-arms b5 mm 540(685) 540(685)
4.32 Ground clearance, center of
wheelbase
m2 mm 30 30
4.34.1 Aisle width for pallets 1000 × 1200
crossways
Ast mm 2145 2145
4.34.2 Aisle width for pallets 800 × 1200
lengthways
Ast mm 2050 2050
4.35 Turning radius Wa mm 1330 1330
Performance data
5.1 Travel speed, laden/ unladen km/ h km/h 4/4.5 5/5.5
5.2 Lifting speed, laden/ unladen m/ s 0.028/0.031 0.020/0.025
