E7
3.2.1 Tyre size, driving
wheels(diameter×width)
mm Ф210x70 Ф210x70 Ф250x102
3.3.1 Tyre size, loading
wheels(diameter×width)
mm 2x Ф78x60
(Ф78x88)
Ф80x61 2×Ф82x85/
Ф82×115
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф74x48 / Ф74x48
3.5 Wheels, number driving,
caster/loading (x=drive
wheels)
mm 1×,2/4(1× 2/2) 1x,-
/
4 1×,2/4(1× 2/2)
3.6.1 Track width, front,driving side b10 mm 438 / 441
3.7.1 Track width,rear,loading side b11 mm 390 390 370/(515)
Dimensions
4.4 Lift height h3 mm 115 115 140
4.9 Height drawbar in driving
position min./max.
h14 mm 700 / 1170 800 /1200 716 / 1240
4.15 Lowered height h13 mm 80 82 82.5
4.19 Overall length l1 mm 1525 1518 1592
4.20 Length to face of forks l2 mm 375 367 423
4.21 Overall width b1/
b2
mm 600 548 645 / 625
4.22 Fork dimensions s/ e/
l
mm 50/150/1150 50/150/1150 55×170×1170
4.25 Distance between fork-arms b5 mm 540(685) 540 540(685)
4.32 Ground clearance, center of
wheelbase
m2 mm 30 30 27
4.34.1 Aisle width for pallets 1000 ×
1200 crossways
Ast mm 2091 2175 1850
4.34.2 Aisle width for pallets 800 ×
1200 lengthways
Ast mm 2148 2045 2050
4.35 Turning radius Wa mm 1330 1370 1428
Performance data
5.1 Travel speed, laden/ unladen km/
h
km/h 4/4.5 4/4.5 5 / 5.5
5.2 Lifting speed, laden/ unladen m/ s 0.02/0.022 100mm/per
time
0.028/0.04
