27
Weight Transmission trace:
<S> - Character 0x53, 83d.
<SP> - Character 0x20, 32d.
<PPPPPPPPP> - Weight with 9 bytes, without decimal point and left-
justified with zeros (0x30).
<UU> - Units. The possible values are: (G_), (KG), (OZ),
and (LB). The scale always sends (G_).
<CR> - Character 0x0d, 13d.
<LF> - Character 0x0a, 10d.
Invalid Result trace:
<S> - Character 0x53, 83d.
<I> - Character 0x49, 73d.
<SP> - Character 0x20, 32d.
<CR> - Character 0x0d, 13d.
<LF> - Character 0x0a, 10d.
Autozero request
TPV Scale
<T><CR><LF>
<T> - Character 0x55, 85d.
<CR> - Character 0x0d, 13d.
<LF> - Character 0x0a, 10d.
When the scale receives this request, it performs an Autozero request. At the
end of the sequence, irrespective of whether or not the scale has been able to
Autozero, it sends the 'Invalid Result' trace in reply.
TPV 2A (UNIWELL-ICL Protocol):
In order to operate with the Uniwell-ICL protocol, you must select the value
''TYPE 2A'' in the ''CONEX TPV'' option.
