SECTION 11: SPECIFICATIONS
Fusion Pro Laser Technical Specifications
Fusion Pro 32 (CO2) Fusion Pro 48 (CO2)
Maximum
Engraving Area
32” x 20” (812 x 508 mm) 48” x 36” (1219 x 914 mm)
Max Material
Thickness
12.25” (311 mm) (2” lens) 12.25” (311 mm) (2” lens)
Laser Source
Wattages
50, 60, 80, or 120 watt, CO2, air-cooled, metal Waveguide tube, 10.6 micrometers
Standard
Features
Radiance High Definition Optics (CO2), Air Assist, Red Dot Pointer, relocatable Home Position,
LED lighting, integrated floor stand, brushless servo motors, Super-Silent Cooling Fans, Joy-
stick controls, removable exhaust plenum.
Intelligent
Memory Buer
Store unlimited files up to 1 GB. Rolling buer allows files of any size.
Operating Modes Optimized Raster, Vector and Combined modes.
Motion Control
System
High-speed, continuous-loop, brushless DC servo motors using rotary encoding technology
for precise positioning.
X-axis Bearings Ground and polished, stainless steel, Teflon coated, self-lubricating bearings. Dual blocks on
X-axis for greater rigidity
Belts Advanced B-style Kevlar belts (X-axis) and steel cord (y-axis).
Resolution Fully-flexible and user-controlled from 75 to 1200 DPI.
Speed and
Power Control
(engraving depth)
Computer-controlled in .001 increments up to 100%. Color mapping feature links Speed,
Power, Frequency, Raster/Vector mode, & Air Assist On/O settings to any RGB color
Print Inteace 10Base-T Ethernet, USB, or Wireless connection. Compatible with Windows XP/Vista/7/8/10.
Size (W x D x H) 54.6” x 34.2” x 42” (1387 x 869 x 1067 mm) 70.6” x 51.3” x 42.75” (1794 x 1304 x 1086 mm)
Pedestal removed: 34” H (863 mm)
Weight 400 lbs (182 kg) 500 lbs. (227 kg)
Electrical
Requirements
Auto-switching power supply accommo-
dates 110 to 240 volts, 50 or 60 Hz, single
phase.
240 volts, 50 or 60 Hz, single phase, 15 amp AC.
Ventilation
Systems
400 CFM for primary exhaust port (upper
port) and 400 CFM for downdra exhaust
port (lower port), totaling 800 CFM.
200 CFM per upper exhaust port and 400 CFM
for the downdra exhaust port (lower port),
totaling 800 CFM.
Exhaust Ports One output Port 4” (102 mm) Two output ports 4” (102 mm)
Vacuum Table
Port
Additional port for dedicated exhaust through table, 4” (102 mm)
Laser System
Classification
Class 2 Laser Product - 1 mW CW Maximum 600-700 nm.
Technical specifications and product configurations subject to change without notice.
