Epiroc SB Series User Manual

Safety and operating instructions
26 © Construction Tools PC AB | 9800 1273 01 | 2020-04-03
Original Instructions
11 Technical data
11.1 Machine data
SB 702 SB 1102
Part number 8460 0300 85 8460 0300 90
Service weight, kg (lb) 720 (1600) 1060 (2300)
Delivery weight, kg (lb) 521 (1149) 789 (1739)
Suitable carrier weight class, t (lbs) 10-17 (22000-37500) 13-24 (29000-53000)
Working length of working tool in standard version, mm (in.) 520 (20.5) 610 (24)
Working tool diameter, mm (in.) 105 (4.13) 120 (4.72)
Start up mode AutoStart AutoStart
Hose inside diameter P, mm (in.) 25 (1) 25 (1)
Hose inside diameter T, mm (in.) 25 (1) 25 (1)
11.2 Capacities
SB 702 SB 1102
Oil flow, l/min (gpm) 80-120 (21-32) 100-135 (26-36)
Impact rate, bpm 600-1050 550-850
Operating pressure, bar (psi) 120-170 (1740-2465) 130-180 (1885-2610)
Maximum hydraulic input power, kW (hp) 34 (45.6) 40 (54.3)
Back pressure acceptance, bar (psi) 20 (290) 20 (290)
Accumulator gas pressure, bar (psi) 60 (870) 70 (1015)
Pressure relief valve on breaker, bar (psi) 205 (2973) 215 (3118)
Water pressure, bar (psi) 4 (58) 4 (58)
Water consumption, l/min (gpm) ≤ 11 (≤ 2.9 ) ≤ 11 (≤ 2.9 )
Air pressure, bar (psi) 2 (29) 2 (29)
Air flow, m
3
/min (ft
3
/min) ≤0.73 (≤26) ≤0.73 (≤26)
