13
Battery Status indicator
GREEN ON when battery voltage in normal range
GREEN SLOWLY FLASHING when battery full
ORANGE ON when battery under voltage
RED ON when battery over discharged
Please refer to section 5 for troubleshooting.
Battery status LED indicator Table 4-2
Color
Indicator
Battery Status
Green
On solid
Normal
Green
Slowly Flashing
Full
Orange
On solid
Under voltage
Red
On solid
Over discharged
 Load status indicator
When the load current is 1.25times of rated current for 60 seconds, or
the load current is 1.5 times of rated current for 5 seconds (overload); or load
current is more than 3.5 times of rated current(Short Circuit) ,the load
status indictor will be red and flashing. Please refer to section 5 for trouble
shooting.
Load status indicator Table 4-3
Color
indictor
Load status
Red
flashing
Overload or short circuit
 Overheating protection indicator
When heat sink of the controller exceeds 85 ℃, the controller will
automatically cut input and output circuit, Sealed, Gel, Flooded indicator
will be red and flashing simultaneously. Please refer to section 5 for trouble
shooting.
Overheating protection indicator Table 4-4
Color
indictor
System status
Red
Sealed、Gel、Flooded flashing
simultaneously
Controller
overheating
