Setting Up the Cabinet 9
3. Use M4 × 10 screws to fasten joint A and the front panel to the
frame in the order shown below. Fasten the joint only loosely
in this step. It is to be fastened securely later in the assembly
procedure.
4. Fasten the caster fixer and the stoppers to the bottom of the
frame with four M4 × 10 screws.
joint A
front panel
➂
➁
➂
➀
caster fixer
stopper
