Epson Artisan 810/835/837/710/725/730/Epson Stylus Photo PX810FW/TX810FW/PX820FWD/TX820FWD/PX830FWD/PX710W/TX710W/PX720WD/TX720WD/PX730WD/TX730WD
Revision G
Artisan 835/725/PX820FWD/TX820FWD/PX720WD/TX720WD
Adjustment 275
Confidential
8.4.2 Required Adjustments (
Artisan 835/725/
PX820FWD/TX820FWD/PX720WD/TX720WD
)
Table 8-4 lists the required adjustments depending upon the parts being repaired or
replaced. Find the part(s) you removed or replaced, and check which adjustment(s)
must be carried out.
Note : <Meaning of the marks in the table>
“O” indicates that the adjustment must be carried out. “O*” indicates that the
adjustment is recommended. “---” indicates that the adjustment is not required.
If you have removed or replaced multiple parts, make sure to check the required
adjustments for the all parts. And when multiple adjustments must be carried out, be
sure to carry out them in the order given in the “Priority” row.
Note *1 : " 5.4.1 I/S Decompress (p238) " is carried out before disassembling. Those with
priority 2 or lower are performed after appropriate removal/replacement. (See "
4.2.5.1 Printhead (p133) ".)
*2 : Artisan 835/PX820FWD/TX820FWD only.
*3 : Artisan 725/PX720WD/TX720WD only. (See " 8.4.4 Touch Panel Calibration
(p279) ".)
*4 : Artisan 725/PX720WD/TX720WD only. (See " 8.4.5 Touch Panel Operation Check
(p279) ".)
*5 : Perform only "Check 1 (p220)".
*6 : Carry out this operation after removing the Waste Ink Tray Assy.
*7 : Carry out PG Inspection (p233) only, if the position of the notch on the Parallelism
Adjustment Busings have not changed.
When the EEPROM Data Copy cannot be made for the main
board that needs to be replaced, the Waste Ink Tray Assy, the
Lower Paper Guide Waste Ink Pad Assy and CDR Tray Assy
must be replaced after replacing the main board with a new
one.
After all required adjustments are completed, use the “Final
check pattern print” function to print all adjustment patterns
for final check. If you find a problem with the printout patterns,
carry out the adjustment again.
When using a new main board for replacing the Printer
Mechanism, the Initial setting must have been made to the main
board.
See Chapter 5 "ADJUSTMENT" for the adjustments other than "
8.4.4 Touch Panel Calibration (p279) " and " 8.4.5 Touch Panel
Operation Check (p279) ".
Table 8-4. Required Adjustment List (
Artisan 835/725/PX820FWD/TX820FWD/PX720WD/TX720WD
)
Priority
1 2 3 4 5 6 6
7
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
I/S decompress
*1*6
Leak check
PG adjustment/PG inspection
CR timing belt tension inspection
PF timing belt tension inspection
Touch Panel adjustment
*2
Touch Panel calibration
*3
Touch Panel operation check
*4
EEPROM Data copy
Initial setting/MAC address setting
PG offset value adjustment
CD-R print counter clear
Memory card check
Consumables maintenance counter
Head ID input
Ink charge
Head angular adjustment
PF adjustment
First dot position adjustment/
PW adjustment
Bi-D adjustment
Top margin adjustment
PF deterioration offset (initialize)
PF deterioration offset (max value writing)
CR motor heat protection control
PF motor heat protection control
BRS adjustment
PFP adjustment
Final check pattern print
Case open sensor check
*5
Main board
Remove
--- --- --- --- --- --- --- --- --- --- --- --- O --- --- --- --- --- --- --- --- --- --- --- --- --- --- O O
Replace
(Read OK)
--- --- --- --- --- --- --- --- O --- --- --- O --- --- --- --- --- --- --- --- --- --- --- --- --- --- O O
Replace
(Read NG)
--- --- --- --- --- O O O --- O O --- O O O --- O O O O O --- O O O O O O O
To Next Page
