Connecting a microphone

You can output microphone audio from the projector's speaker by connecting a commercially available dynamic microphone.

• Plug-in-power is not supported.

• Adjust Mic Input Level if the microphone audio is difficult to hear, or if it is too loud resulting in a crackling sound.

s Settings - Mic Input Level p.101

• Make the following settings to output audio from a microphone when the projector is in standby mode.

Set Standby Mode to Communication On.

Extended - Standby Setup - Standby Mode p.103

Set Standby Microphone to On. s Extended - Standby Setup - Standby Microphone p.103
