Details of Updated Optional Accessories (Version 2.00)
8
Refer to these sections for more details about newly supported optional
accessories.
gg Related Links
• "ELPLW08 Support" p.8
• "ELPLM15 Support" p.10
ELPLW08 Support
You can use lens unit ELPLW08 with your projector when you update the
firmware to version 2.00. Refer to these sections for the technical details of
lens unit ELPLW08.
gg Related Links
• "ELPLW08 Lens Shift Range" p.8
• "ELPLW08 Keystone Correction Range" p.9
• "ELPLW08 Curved Surface Correction Range" p.9
• "ELPLW08 Corner Wall Correction Range" p.9
• "ELPLW08 Projection Distance" p.10
ELPLW08 Lens Shift Range
The following figure shows the ranges within which you can shift the image
using the lens shift feature.
a
You cannot shift the lens to both the horizontal and vertical maximum
values.
EB‑‑G7905U/EB‑‑G7900U/EB‑‑G7500U/EB‑‑G7400U/EB‑‑G7200W/EB‑‑G7000
W
A
Center of the lens
B
Projected image when the lens position is moved to the home position
C
Maximum motion range: V × 67%
D
Horizontal direction at maximum value: V × 19%
EB‑‑G7805/EB‑‑G7800/EB‑‑G7100
