Adjusting the Image Position Using Lens Shift
45
D
When the horizontal direction is at the maximum value: V × 12%
• EB‑L610
A
Center of lens
B
Projected image when the lens is set to the home position
C
Maximum range: V × 50%
D
When the horizontal direction is at the maximum value: V × 5%
a
You cannot move the image horizontally when the lens is shifted
vertically all the way.
