Image Shape
52
a
• If you see this screen, you cannot adjust the shape any further
in the direction indicated by the gray triangle.
h
Repeat steps 6 and 7 as needed to adjust any remaining corners.
i
When you are finished, press [Esc].
gg Related Links
• "Projector Feature Settings - Settings Menu" p.155
Correcting Image Shape with Arc Correction
You can use the projector's Arc Correction setting to adjust the shape of an
image projected on a curved or spherical surface.
a
Turn on the projector and display an image.
b
Press the [Menu] button on the control panel or remote control.
c
Select the Settings menu and press [Enter].
d
Select Geometry Correction and press [Enter].
