Select Extended > Multi-Projection > Simple Blending, and press
[En
ter]. en press [Enter] again if necessary.
d
Select the Location Setup setting and specify the position of the primary
p
rojector from A1 or B1.
e
Select the image aspect in the Who
le Screen Aspect setting for the
merged wide image.
You can set the following aspects using the W
ho
le Screen Aspect
menu.
•
21:9(EDID 3440x1440)
•
21:9(EDID 2560x1080)
•
16:6(EDID 2880x1080)
•
16:6(EDID 1920x720)
•
3:1(EDID 3240x1080)
•
32:10(EDID 3456x1080)
•
32:9(EDID 3200x900)
f
Perform S
tart Auto Adjustment.
F
ollow the on-screen instructions to adjust the projection position. If the
projection position cannot be adjusted fully using the [Lens Shi] button
on the remote control or the [Lens] button on the control panel, move the
projectors so that the green pattern and the magenta pattern overlap and
turn white.
g
Aer au
to adjustment is complete, perform Correct Shape following the
in
structions on the screen.
h
Perform Screen Matching to adjust the brightness and tint of the images.
If you have problems with simple blending not being applied correctly, try
th
e following solutions:
•
Make sure the projectors are placed correctly and connected using a
LAN cable.
•
Make sure the optional external camera is installed correctly and the
cable is securely connected to the projector.
•
e optional external camera may be defective. Contact Epson for help.
•
Make sure that a powerful spotlight or source of strong natural light
is not shining into the projection environment and interfering with
simple blending.
•
Resize the projection size.
•
If you see an error message during the simple blending process, check
the error codes in the message.
•
0402: Measurement failure
•
0406: Geometry correction error
•
0407/0408: e external camera may be defective, or a
communication error has occurred.
Contact Epson for support for details.
Projecting One Large Unied I
mage in a Daisy
-Chain
Connection
You can create one large unied
image from multiple projectors.
You can connect multiple projectors using either of the following methods:
daisy-chain connection or distributor connection. You can connect up to four
projectors in a daisy-chain connection.
Details of User Operation Change (Version 1.10)
