EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480
Disassembly and Assembly CONFIDENTIAL
SEIKO EPSON 92 Revision C
Secure the AC Inlet and the ferrite core of PS Filter as follows.
• Fit the ferrite core in the core holder.
• Fit the AC Inlet in the AC Inlet holder.
Core holder
Ferrite Core
AC Inlet
AC Inlet holder
To Next Page
