Crestron Connected Support
121
h
When you finish selecting settings, click Exit to exit the program.
gg Related Links
"Crestron Connected Operation Window" p.121
"Crestron Connected Tools Window" p.122
Crestron Connected Operation Window
Settings on the operation window let you control the projector and adjust the
projection image.
A
Power Turns the projector on or off.
Vol-/Vol+ Adjusts the volume.
A/V Mute Turns the video and audio on or off.
B
Switches to the image from the selected input source. To display input sources
that are not shown in Sources List, click (a) or (b) to scroll up or down. The
current video signal input source is displayed in blue.
You can change the source name if necessary.
C
Freeze Images are paused or released.
Contrast Adjusts the difference between light and shade in the
images.
Brightness Adjusts the image brightness.
Color Adjusts the color saturation for the images.
Sharpness Adjusts the image sharpness.
Zoom Enlarges or reduces the image without changing the
projection size. Click the arrow buttons to change the
position of an enlarged image.
D
Arrow buttons Performs the same operations as the arrow buttons on
the remote control.
OK Performs the same operation as [Enter] on the remote
control.
Menu Displays and closes the projector's menu.
Auto Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from Computer1 or Computer2 port.
Search Changes to the next input source that is sending an
image.
Esc Performs the same operation as the [Esc] button on the
remote control.
E
Tools Changes settings in the projector that is currently
connected.
Info Displays information on the projector that is currently
connected.
Help Displays the Help Desk window. Used to send
messages to, and receive messages from, the
administrator using Crestron RoomView Express.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-X49 and is the answer not in the manual?

Epson EB-X49 Specifications

General IconGeneral
Matrix size0.55 \
Number of colors1.07 billion colors
Native aspect ratio4:3
Projection distance- m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Contrast ratio (typical)16000:1
Screen size compatibility30 - 300 \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2400 ANSI lumens
RMS rated power5 W
Number of built-in speakers1
Lamp typeUHE
Lamp power210 W
Light source typeLamp
Service life of light source6000 h
Service life of light source (economic mode)12000 h
PlacementCeiling, Desktop
Product typeStandard throw projector
Product colorWhite
Market positioningPortable
Cable lock slot typeKensington
Built-in displayNo
FocusManual
Throw ratio1 - 1.2:1
Focal length range16.9 - 20.28 mm
Aperture range (F-F)1.49 - 1.72
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Power consumption (typical)327 W
Power consumption (economy mode)225 W
Video processing10 bit
Video color modesDynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system-
HDMI connector typeFull-size
Serial interface typeRS-232C
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity3
Component video (YPbPr/YCbCr) in0
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Bundled softwareEasyMP Multi PC Projection, Epson Projektor Management
Noise level37 dB
Preset modesBlackboard, Dynamic, Presentation, Theatre, sRGB
Country of originPhilippines
Noise level (economic mode)28 dB
USB display function3 in 1: Image / Mouse / Sound
Supported network protocolsPJLink
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet78 pc(s)
Harmonized System (HS) code85286200
Software supportvia: AMX, Crestron (Network), Control4, Extron
Weight and Dimensions IconWeight and Dimensions
Depth249 mm
Width302 mm
Height87 mm
Weight2700 g
Package depth380 mm
Package width355 mm
Package height160 mm
Package weight4120 g
