Epson EB-X49 User Manual

Projector Lamp Maintenance
163
The projector monitors the number of hours the lamp is used and displays
this information in the projector's menu system.
Replace the lamp as soon as possible when the following occurs:
• The projected image gets darker or quality declines
• A message is displayed when you turn on the projector telling you to replace
the lamp (the message is displayed 100 hours before the expected end of the
lamp life and appears for 30 seconds)
• The projector's power indicator is flashing blue and its lamp indicator is
flashing orange.
Attention
• If you continue to use the lamp after the replacement period has passed, the
possibility that the lamp may explode increases. When the lamp replacement
message appears, replace the lamp with a new one as soon as possible, even if it
is still working.
• Do not repeatedly turn off the power and then immediately turn it back on.
Turning the power on and off frequently may shorten the lamp's operating life.
• Depending on the characteristics of the lamp and the way it has been used, the
lamp may become darker or stop working before the lamp warning message
appears. You should always have a spare lamp unit ready in case it is needed.
• We recommend the use of genuine Epson replacement lamps. The use of non-
genuine lamps may affect projection quality and safety. Any damage or
malfunction caused by the use of non-genuine lamps may not be covered by
Epson's warranty.
gg Related Links
• "Replacing the Lamp" p.163
• "Resetting the Lamp Timer" p.166
• "Projector Specifications" p.194
• "Projector Indicator Status" p.169
Replacing the Lamp
You can replace the lamp while the projector is placed on a table or mounted
to the ceiling.
Warning
• Let the lamp fully cool before replacing it to avoid injury.
• Never disassemble or modify the lamp. If a modified or disassembled lamp is
installed in the projector, it could cause a fire, electric shock, or other damage or
injury.
a
Turn off the projector and unplug the power cord.
b
Allow the projector lamp to cool down for at least one hour.
c
Use the screwdriver included with the replacement lamp to loosen the
screw securing the lamp cover.

Epson EB-X49 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2400 ANSI lumens
RMS rated power	5 W
Number of built-in speakers	1
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Built-in display	No
Focus	Manual
Throw ratio	1 - 1.2:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video processing	10 bit
Video color modes	Dynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system	-
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projektor Management
Noise level	37 dB
Preset modes	Blackboard, Dynamic, Presentation, Theatre, sRGB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	249 mm
Width	302 mm
Height	87 mm
Weight	2700 g
Package depth	380 mm
Package width	355 mm
Package height	160 mm
Package weight	4120 g
