Epson EB-X49 User Manual

Projector Parts and Functions
22
Name Function
A
Power button [ ]
Turns the projector on or off.
B
[HDMI] button Switches the image source between the HDMI ports.
C
[Computer] button Switches the image source to the Computer ports.
D
Numeric buttons Enters numbers in the projector's menu while holding
down the [Num] button.
E
[Auto] button Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from the Computer ports.
F
[Num] button Hold down this button to enter numbers using the
numeric buttons.
G
[Menu] button Displays and closes the projector's menu.
H
Arrow buttons Selects menu items while displaying the projector's
menu.
I
[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu.
J
[User] button Performs settings assigned in the User Button setting
in the projector's Settings menu.
K
[Color Mode] button Changes the color mode.
L
[Aspect] button Changes the aspect mode.
M
[E-Zoom] +/–
buttons
Resizes the projected image.
N
[A/V Mute] button Turns the video and audio on or off temporarily.
O
[Split] button Projects two images from different image sources
simultaneously by splitting the projected screen.
P
[Home] button Displays and closes the Home screen.
Q
[Freeze] button Pauses or resumes images.
R
[Volume] up/down
buttons
Adjusts the speaker volume.
S
[Default] button Returns the selected setting to its default value.
Name Function
T
[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
U
[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
using the remote control.
V
[LAN] button Switches the image source between the network
connected devices.
W
[USB] button Switches the image source between the USB Display
and USB-A port.
X
[Source Search]
button
Switches to the next input source.
Y
Remote control light
emitting area
Outputs remote control signals.
gg Related Links
• "Image Aspect Ratio" p.58
• "Adjusting Image Quality (Color Mode)" p.61
• "Input Signal Settings - Signal Menu" p.131
• "Projector Setup Settings - Extended Menu" p.134
• "Home Screen" p.40
• "Projecting Two Images Simultaneously" p.65
• "Connecting to a Computer for USB Video and Audio" p.28
• "Projecting a PC Free Presentation" p.68
• "Using the Projector on a Network" p.87

Epson EB-X49 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2400 ANSI lumens
RMS rated power	5 W
Number of built-in speakers	1
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Built-in display	No
Focus	Manual
Throw ratio	1 - 1.2:1
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video processing	10 bit
Video color modes	Dynamic, Cinema, Presentation, sRGB, Blackboard
Analog signal format system	-
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection, Epson Projektor Management
Noise level	37 dB
Preset modes	Blackboard, Dynamic, Presentation, Theatre, sRGB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB display function	3 in 1: Image / Mouse / Sound
Supported network protocols	PJLink
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	78 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4, Extron

Weight and Dimensions

Depth	249 mm
Width	302 mm
Height	87 mm
Weight	2700 g
Package depth	380 mm
Package width	355 mm
Package height	160 mm
Package weight	4120 g
