Preparing

24

Remote Control Operating Range

The operation range for the WirelessHD Transmitter differs.

s

p.58

Operating range (left to right)

10m

10m

30°

30°

30°

30°

Operating range (top to bottom)

10m

10m

30°

10°

60°

30°
