Epson EH-TW9000 - Dimensional Drawings

EH-TW8000/TW9000/TW9000W Product Description CONFIDENTIAL
SEIKO EPSON 14 Revision A
1.3 Dimensions
5-M4X9
26.6
79.3
90
30
13.4
5.3
56.5 67.4
33.8
36
133.5
62.381.9
103.2
233
158.5
396
88.2
198
60
319.4
466
88.4
233
300
160
358.9
83
395.5
47.2
Unit: mm
