EH-TW8000/TW9000/TW9000W Troubleshooting CONFIDENTIAL
SEIKO EPSON 31 Revision A
CIRCUIT BOARDS
Figure 2-6.
EIF Board (p74)
SW Board (p95)
Optical Engine and MAB Set (p75)
