Epson ES-400 II

To Next Page

To Previous Page

Scanner Parts

Note: The illustrations show the ES-500W II, but the parts are the same for the ES-400 II.

1 ADF (Automatic Document Feeder)

2 Edge guides

3 Input tray

4 Input tray extension

5 Output tray

6 Output tray extensions
