Epson FX-2190IIN User Manual

Chapter 6 Options and Consumables
Replacing the Ribbon Cartridge.......................................................... 119
Genuine Epson ribbon cartridge..................................................... 119
Replacing the ribbon cartridge...................................................... 119
Cut-Sheet Feeder...................................................................... 123
Installing the cut-sheet feeder....................................................... 124
Loading paper in the single-bin cut-sheet feeder........................................ 126
Loading paper in the high-capacity cut-sheet feeder..................................... 129
Assembling the double-bin cut-sheet feeder........................................... 132
Selecting the paper path (bin 1 or bin 2)............................................... 133
Roll Paper Holder..................................................................... 134
Assembling the roll paper holder.................................................... 134
Installing the roll paper holder...................................................... 135
Loading roll paper. . . . . . . .......................................................... 135
Removing roll paper............................................................... 138
Additional Tractor Unit................................................................ 138
Additional Sheet Guide................................................................. 138
Chapter 7 Product Information
Printer Parts.......................................................................... 139
Printer Specifications.................................................................. 141
Mechanical...................................................................... 141
Electronic........................................................................ 144
Electrical........................................................................ 145
Environmental................................................................... 146
Paper........................................................................... 147
Recommended printable area....................................................... 151
Command Lists....................................................................... 153
Epson ESC/P control codes......................................................... 153
IBM PPDS emulation control codes.................................................. 154
Standards and Approvals. .............................................................. 155
Safety approvals................................................................... 155
Cleaning the Printer................................................................... 156
Transporting the Printer................................................................ 157
Glossary
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Contents 7

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
