Epson FX-2190IIN User Manual

10. Pause button
❏ Stops printing temporarily, and resumes printing when pressed again.
❏ Press and hold for three seconds to enter Micro Adjust mode. Press again to exit Micro Adjust
mode.
11. Paper Out light
❏ On when no paper is loaded in the selected paper source or paper is not loaded correctly.
❏ Flashes when paper has not been fully ejected or a paper jam has occurred.
12. Tear Off/Bin lights
❏ Both of the two lights flash when continuous paper is in the tear-off position, and both of the lights
are off when continuous paper is not in the tear-off position.
❏ The left light is on when Card mode is selected.
❏ Both the lights are off when bin 1 of the optional cut-sheet feeder is selected.
❏ The right light is on when bin 2 of the optional cut-sheet feeder is selected.
13. Pitch lights
Indicate which pitch is selected.
14. Font lights
Indicate which font is selected.
Selecting a Font and Pitch
You can select one of the printer’s five fonts and pitch by using the buttons on the printer’s control
panel, as described below.
Note:
❏ Settings you make in application programs usually override settings you make from the printer’s
control panel. For best results, use your application to select a font and make other settings.
❏ The available pitch depends on the font you select. See the table below for more information.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Control Panel 90

Epson FX-2190IIN Specifications

General

Color	-
Bitmap fonts	Draft, OCR-B, Roman, Sans Serif
Character sets	Italic, PC437, PC850, PC858, Roman 8
Character pitch	10, 12 cpi
Built-in barcodes	CODABAR (NW-7), Code 128 (A/B/C), Code 39, Industrial 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E
Maximum resolution	240 x 144 DPI
Number of characters	42
Maximum number of copies	6 copies
Maximum print speed (NLQ)	115 cps
Maximum print speed (draft)	612 cps
Maximum printing width (columns)	136
Print yield	12 characters
Print direction	Bi-directional
Ribbon life (black, draft)	12 million characters
Mean time between failures (MTBF)	25000 h
Sustainability certificates	ENERGY STAR
Standard interfaces	Ethernet, Parallel, USB
Paper tray media types	Envelopes
Single sheet thickness range	0.06 - 0.14 mm
Continuous paper thickness range	0.46 - 0.46 mm
Multi-part paper thickness range	0.12 - 0.46 mm
AC input voltage	198-264 V
Power consumption (standby)	10 W
Power consumption (typical)	55 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 60 %
Operating relative humidity (H-H)	10 - 80 %
Product color	Black
Country of origin	Indonesia
Sound pressure level (printing)	55 dB
Needles	18 (2 x 9)
Print technology	Dot matrix
Connectivity technology	Wired
Pallet width	800 mm
Pallet height	2250 mm
Pallet length	1200 mm
Pallet weight	0 g
Pallet width (UK)	1000 mm
Quantity per pallet	14 pc(s)
Quantity per pallet (UK)	21 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	84433210
Quantity per pallet layer (UK)	3 pc(s)
Package depth	735 mm
Package width	455 mm
Package height	300 mm
Package weight	12160 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	612 mm
Height	177 mm
