Epson L200 Service Manual

Confidential
Disassembly/Reassembly Overview 13
L200/L201/L100/L101 Revision A
 Points to be checked before packing the printer

The Valve Lever is on the position shown below
(the Choke Valve is closed). (See Figure 1-2.)
 All the caps of the Ink Supply Tank Assy are
securely closed.
 The hooks (x2) of the Ink Supply Tank Assy are
securely engaged with the Ink Supply Holder Assy.
 The opened ink bottle is not included in the box.
Valve Lever
Cap
Ink Supply
Tank Assy
Ink Supply Holder Assy

Epson L200 Specifications

General

Print Technology	On-demand inkjet (piezoelectric)
Print Resolution	5760 x 1440 dpi
Print Speed (Black)	27 ppm
Print Speed (Color)	15 ppm
Connectivity	USB 2.0
Paper Capacity	100 sheets
Scanner Type	Flatbed
Scanner Resolution	600 x 1200 dpi
Functions	Print, Scan, Copy
Paper Sizes	A4, A5, A6, B5, C6, DL
Ink Tank System	Yes
Ink Colors	Black, Cyan, Magenta, Yellow
Display	No
Ink Type	Dye Ink
Dimensions	472 x 300 x 145 mm
