Epson L200 Service Manual

Confidential
Disassembly/Reassembly Overview 9
L200/L201/L100/L101 Revision A
1.1 Overview
This chapter describes procedures for disassembling the main parts/units of L200/L201/L100/L101. Unless
otherwise specified, disassembled parts/units can be reassembled by reversing the disassembly procedure. See
the cautions or tips for disassembly/reassembly described in “ 1.3 Details of Disassembling/Reassembling by
Parts/Unit (p23)”.
Read the following before disassembling and reassembling.
 “ Safety Precautions (p3)”
 “ 1.1.2 Checks and precautions before disassembling (p10)”
When you have to remove units or parts that are not described in this chapter, see the exploded diagrams of SPI
(Service Parts Information).
1.1.1 Tools
Use only specified tools to avoid damaging the printer.
Note *: All of the tools listed above are commercially available.
EPSON provides the tools listed with EPSON part code.
Table 1-1. Tools
Name EPSON Part Code*
(+) Phillips screwdriver #1 1080530
(+) Phillips screwdriver #2 ---
Flathead screwdriver ---
Flathead Precision screwdriver #1 ---
Tweezers ---
Longnose pliers ---
Acetate tape 1003963
Nippers ---

Epson L200 Specifications

General

Print Technology	On-demand inkjet (piezoelectric)
Print Resolution	5760 x 1440 dpi
Print Speed (Black)	27 ppm
Print Speed (Color)	15 ppm
Connectivity	USB 2.0
Paper Capacity	100 sheets
Scanner Type	Flatbed
Scanner Resolution	600 x 1200 dpi
Functions	Print, Scan, Copy
Paper Sizes	A4, A5, A6, B5, C6, DL
Ink Tank System	Yes
Ink Colors	Black, Cyan, Magenta, Yellow
Display	No
Ink Type	Dye Ink
Dimensions	472 x 300 x 145 mm
