Epson L365 Service Manual

Confidential
Troubleshooting Fatal Error Code List 15
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
Note "*": Not occurs except in manufacturing process.
Printer
0xF2 PF PID excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Motor driver failure (Main Board failure)
• Slipping gears have occurred around the PF Motor gears.
0xF3 PF PID reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Slipping gears have occurred around the PF Motor gears.
• Paper jam
0xF4 PF PID lock error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xF8 PF load position reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Slipping gears have occurred around the PF Motor gears.
0xF9 PF load position reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Motor driver failure (Main Board failure)
• Slipping gears have occurred around the PF Motor gears.
0xFA PF load position excess load error
• PF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xFE PF PID driving time error
• Main Board failure
0xFF PF load position excess driving time error
Error type
Error
code
Error name Possible cause
