Epson L365 Service Manual

L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
Disassembly/Reassembly Detailed Disassembly/Reassembly Procedure for each Part/Unit 46
Confidential
PF Grounding Spring
When installing the PF Grounding Spring, follow the procedure below.
1. From the left side of the printer, insert the spring leg A of the
PF Grounding Spring into the hole of the Frame Base.
2. Insert the spring leg B of the PF Grounding Spring into the
groove of the Frame Base.
3. Attach the spring leg B of the PF Grounding Spring to the
cutout of the Main Frame to install the PF Grounding Spring.
Insert spring leg
A into groove.
PF Grounding
Spring
Left
Main Frame
Spring leg B
Cutout
PF Grounding
Spring
Spring leg B
Spring leg A
Frame Base
Assy
Hole
Top Cover
When attaching the Top Cover Label, align it with the markings on
the Top Cover as shown in the figure above.
Top Cover
Top Cover Label
Top Cover
 Color indication on Ink Tank is deleted. Color position is
specified on Top Cover.
No color position
Color position
Ink Supply Tank Assy
 Be careful not to damage or peel off the film of the Ink Supply
Tank.
 Be careful about how to place the Ink Supply Tank Assy in
order to prevent printing failure from occurring. (See
"2.1.5Checks and Precautions before Disassembling (p25)" .)
Film
Ink Supply Tank
Cover / Guide Tube Tank
Follow the procedure below when removing the Cover Tube Tank and Guide Tube Tank.
1. Removing the screw (x1) of the Cover Tube Tank from Ink Supply Tank Assy.
2. Removing the screw (x2) of the Cover Tube Tank .
3. Removing the hooks (x2) of the Cover Tube Tank and separating Cover Tube Tank and Guide Tube Tank.
1
Ink Supply
Tank Assy
Cover Tube
Tank
C.B.P-TITE SCREW 3x6 F/ZN-3C (4 ± 1
Back side
Guide Tube Tank
Cover Tube
Tank
Hook
Guide Tube Tank
Right side
2
3
Cover / Guide Tube Tank
Follow the procedure below when installing the Cover Tube Tank and Guide Tube Tank.
1. Joint the Cover Tube Tank to Guide Tube Tank and tighten the screw (x1) of the Cover Tube Tank.
2. Insert the dowels (x2) of the Cover Tube Tank to the positioning Hole (x2) of the Ink Supply Tank Assy.
3. Tighten the screw (x2) of the Cover Tube Tank.
Ink Supply
Tank Tube
Guide Tube
Tank
C.B.P-TITE SCREW 3x6 F/ZN-3C (4 ± 1
1
2
DowelPositioning Hole
Cover Tube
Tank

Epson L365 Specifications

General

Duplex printing	No
Print technology	Inkjet
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	9.2 ppm
Print speed (color, normal quality, A4/US Letter)	4.5 ppm
Maximum copy resolution	- DPI
Scanner type	Flatbed scanner
Scan speed (black)	7.2 ppm
Scan speed (color)	14.3 ppm
Image formats supported	JPG
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Country of origin	Philippines
Maximum duty cycle	- pages per month
Number of print cartridges	4
Total input capacity	100 sheets
Total output capacity	30 sheets
Paper tray media types	Envelopes, Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
ISO C-series sizes (C0...C9)	C6
Maximum ISO A-series paper size	A4
Wi-Fi	Yes
Security algorithms	128-bit WEP, 64-bit WEP, WPA-EAP, WPA-PSK, WPA-TKIP
Standard interfaces	USB 2.0, Wireless LAN
Sound pressure level (printing)	38 dB
AC input voltage	110 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.3 W
Power consumption (standby)	1.3 W
Power consumption (average operating)	11 W
Bundled software	Epson Scan
Product color	Black
Market positioning	Home & office
Pallet width	800 mm
Pallet height	2100 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	40 pc(s)
Quantity per pallet (UK)	50 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	5 pc(s)
Package depth	530 mm
Package width	385 mm
Package height	195 mm
Package weight	6320 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	300 mm
Width	482 mm
Height	145 mm
