Epson LQ-2080 Quick Reference Guide

9
Replacing the Ribbon Cartridge
Make sure the print head is not hot; if
it is, let it cool for a few minutes before
touching it. Then slide the print head to
the ribbon installation position (the
indented portion of the paper tension
unit) by hand.
Grasp the used ribbon cartridge and
pull it up and out of the printer.
4 5
Q
When the pull tractor is installed, you
can replace the ribbon cartridge when
the print head is not in the ribbon
installation position.

Epson LQ-2080 Specifications

General

Print Method	Impact dot matrix
Number of Pins	24 pins
Resolution	360 x 360 dpi
Buffer Memory	64 KB
Noise Level	55 dB(A)
Paper Handling	tractor feed
Connectivity	Parallel
Paper Width	101.6 to 406.4 mm
Print Speed	Up to 440 cps (characters per second)
