Optional Interfaces
External 10/100 Base T Ethernet
Printer Language
ESC
®
IBM
®
2380 Plus emulation
Paper Handling
Multi-part Forms
Front 1 original + 4 copies
Rear 1 original + 4 copies
Continuous Feed 4" to 10"
Labels 4" to 10"
Page length 4" to 22"
Sound Level
49 dBA (ISO 7779 pattern)
Power Requirements
Rated voltage 120V AC
Input voltage range 99 to 132V, 198 to 164V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Power Consumption
Approx. 23W (ISO/IEC 10561 Letter Pattern)
Energy Star Compliant
Physical Dimensions
Height 6.26" (159 mm)
Width 14.42" (366 mm)
Depth 10.84" (275 mm)
Weight 9.7 lb (4.4 kg)
Control Panel Functions
4 switches
4 LEDs
Reliability
MTBF 6,000 POH (25% duty cycle)
Print head life 400 million characters
Ribbon life 3 million characters (draft,10 cpi, 14 dots/character)
Warranty
Two-year limited warranty in the U.S. and Canada
Support—The Epson Connection
SM
Pre-Sales Support (US and Canada) (800) 463-7766
Internet Website www.epson.com
* Advanced print head design provides unmatched burst speed, allowing the Epson LX-300+II to maximize performance by
consistently performing at or near top speeds. Standardized ISO 10561 throughput tests illustrate how Epson’s superior
technology results in faster printing and greater print volume over time. Test conducted by Seiko Epson Corporation.
** Additional tractor unit required
Printer Method
9-pin, serial, impact dot matrix, narrow carriage
Print Direction
Text Mode: Bidirectional
Graphics Mode: Unidirectional (bidirectional via software)
Print Speed
High Speed Draft 337 cps (12 cpi)
300 cps (10 cpi)
Draft 225 cps (10 cpi)
Near Letter Quality 56 cps (10 cpi)
Character Sets
13 standard versions
13 international character sets
38 NLSP versions
Resident Bitmapped Fonts
Epson Draft 10, 12, 15 cpi proportional
Epson Roman 10, 12, 15 cpi proportional
Epson San Serif 10, 12, 15 cpi proportional
Epson OCR-B 10 cpi
Bar Code Fonts
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A, UPC-E,
Code 39, Code 128, POSTNET, Code Bar (NW-7)
Column Width
10 cpi 80
Formatting
Line spacing 1/6 or programmable (min 1/216")
Paper Feed Mechanism
Feeding method Friction feed (rear)
Push tractor (rear)
Pull tractor (rear, bottom)
Push and pull tractor (rear)
Paper Feed Speed
Approximately 88 millisecond per 1/6"
3" per second continuous feed
Paper Path
Manual insertion Top in, top out
Cut sheet feeder Top in, top out
Push tractor Rear in, top out
Pull tractor Front or rear in, top out
Input Buffer
64KB
Software Drivers
Windows
®
NT 4.0, 98, 2000, Me, XP, Vista and 7
Interface
Bidirectional Parallel (IEEE -1284 Nibble Mode supported)
USB 1.1, RS-232C Serial
Printer Specifications
Epson LX-300+II
Product Code Description
C11C640001 Epson LX-300+II
8750 Black Ribbon Cartridge
Epson LX-300+II
Product Code Description
C800301 Pull Tractor Unit
C12C811141 Roll Paper Holder
C806371 Cut Sheet Feeder
Ordering Information
Epson LX-300+II
Carton dimensions 14.5" x 17.6" x 8.6" (W x D x H)
Carton weight 12.10 lb
Pallet 32.25" x 83.0" x 45.0" (W x D x H)
Container 54 units per pallet
Packaging Specifications
Printed on Recycled Paper
Specifications and terms are subject to change without notice. Epson, Epson ESC/P@ and Better Product for a Better Future are registered trademarks of Seiko Epson Corporation. Epson Remote Configuration Manager is a trademark and Epson Connection is a service mark of
Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2011 Epson America, Inc. CPD - 10062R2 2/11
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
eco.epson.com
