Disassembly/Reassembly Overview 24
M200 / M205 / M100 / M105 Series Revision A
Housing Ink Supply Tank 1:32 1:32
ADF/SCN Unit 2:46 2:52 5:38
ADF Unit
3:32 2:52 6:24
ADF Hinge Left 5:28 5:28
ADF Document Support
7:06 7:06
ADF Hinge Right 3:53 3:53
Cover Gear Assy 4:29 4:29
Bevel Gear Shaft
4:34 4:34
Combination Gear 24.9.6 4:33 4:33
ADF Frame Assy 5:04 5:04
ADF Front Frame 6:00 6:00
Spur Gear 20.4 / 25.8 6:04 6:04
ADF Driven Gears 6:42 6:42
ADF Upper Frame Assy 6:44 6:44
ADF Pad Assy
7:23 7:23
ADF Base Assy 6:15 6:15
Scanner Unit
3:30 2:52 6:22
Scanner Housing Upper 5:05 5:05
CIS Module Unit 5:28 5:28
Spacer 5:44 5:44
CIS Module 5:44 5:44
Scanner Motor Gear Cover 5:58 5:58
Combination Gear 18.4.9.66 6:05 6:05
Scanner Carriage Unit 6:09 6:09
Scanner Motor 8:25 8:25
CIS Holder Unit 8:25 8:25
Scanner Housing Lower 6:09 6:09
Housing Left
4:19 4:19
Ethernet Cover 4:25 4:25
Panel FFC Cover
3:04 3:04
Hinge 3:02 3:02
Housing Right 5:32 5:32
Strengthen Plate Upper 4:09 4:09
Strengthen Plate Lower 4:10 4:10
Cap Assy
5:06 5:06
Cap Lever 5:15 5:15
Porous Pad for Cap Assy
5:21 5:21
Star Wheel Holder Assy 1:52 3:18 5:10
EJ Roller 3:48 3:18 7:04
Panel Unit 5:27 5:27
Panel Housing Upper Assy 6:01 6:01
Panel Board 7:33 7:33
Panel Button 9:04 9:04
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson M100 Specifications

General

Maximum Print Resolution	1440 x 720 dpi
Connectivity	USB 2.0
Output Tray Capacity	30 sheets
Ink Bottle Capacity	140ml
Weight	3.4 kg
Print Method	On-demand inkjet
Print Speed (Black)	34 ppm
Print Speed (ISO/IEC 24734)	15 ipm
Paper Formats	A4, A5, A6, B5, Letter, Legal
Paper Tray Capacity	100 sheets
Operating Systems	Mac OS 10.5.8 or later, Windows 7, Windows 8, Windows Vista, Windows XP, Windows XP x64
Dimensions	435‎ x 267 x 148 mm (Width x Depth x Height)
