Appendix Protection for Transportation 85
M200 / M205 / M100 / M105 Series Revision A

Singlefunction Printer
Attach the strong tape (3 tapes) to the position on the following diagram and secure the Paper Support/
Paper Support Sub on the Housing Upper Assy.
Figure 5-4. Securing the Paper Support/Paper Support Sub (Singlefunction Printer)
Rear
Paper Support/ Paper
Support Sub
Folded ends
Paper Support/ Paper
Support Sub
Strong tape

Epson M100 Specifications

General

Maximum Print Resolution	1440 x 720 dpi
Connectivity	USB 2.0
Output Tray Capacity	30 sheets
Ink Bottle Capacity	140ml
Weight	3.4 kg
Print Method	On-demand inkjet
Print Speed (Black)	34 ppm
Print Speed (ISO/IEC 24734)	15 ipm
Paper Formats	A4, A5, A6, B5, Letter, Legal
Paper Tray Capacity	100 sheets
Operating Systems	Mac OS 10.5.8 or later, Windows 7, Windows 8, Windows Vista, Windows XP, Windows XP x64
Dimensions	435‎ x 267 x 148 mm (Width x Depth x Height)
