If you’re using IEEE 1394 (FireWire)
Plug one end of the IEEE 1394 cable (not included) into the scanner’s
IEEE 1394 port. Then plug the other end into the IEEE 1394 (FireWire or
iLink) port on your computer.
5 Plug the scanner’s power cord into an electrical outlet.
6 Make sure the cover is closed, then press the P power button on the front of
the scanner to turn it on.
The scanner turns on and the indicator light flashes green. It stops flashing
and turns green when the scanner is ready.
Getting the Most
From Your Scanner
The following sections contain overviews of how to get the most out of your
professional scanner and its software. For detailed instructions, see the
electronic or printed manuals for each software application. The SilverFast
CD-ROM also contains useful QuickTime
®
tutorials.
Enhancing Your Photos
EPSON Scan includes several features to improve your scans, including
DIGITAL ICE
™
Technology, Color Restoration, and Dust Removal (for film).
For details on using these features, see your Quick Guide booklet or on-screen
Perfection 4870 Reference Guide.
Managing Color Data
You can use MonacoEZcolor
™
and your device software to provide accurate color
data among all your computer input and output devices such as your scanner,
monitor, digital camera, and printer. Here are the basic steps you need to take to
manage color for scans that you will print. See your MonacoEZcolor online
guides for detailed instructions.
1 First you need to use the Create Printer Profile option in MonacoEZcolor to
create profiles for your scanner and printer.
You must create profiles for each type of print media and settings.
Print an RGB Target with the printer, type of paper, and settings you will use
when printing images.
2 Open Adobe Photoshop Elements and choose Full Color Management -
Optimized for Print under the Color Settings.
3 Select File > Import > SilverFast (Epson). Then prescan your image and
adjust the marquee.
4 Click the General tab, then click the Option (or Options) button. Click the
CMS tab.
5 For the Input -> Internal setting, select Image Color Matching (ICM) in
Windows or ColorSync in Macintosh.
6 For the Internal -> Output setting, select <RGB>.
7 For the Scanner (Reflective), select the scanner profile you created with
MonacoEZcolor in step 1. For the Internal setting, select a working space
that has a wide color gamut, such as Adobe RGB (1998).
8 Make sure the Embed ICC profile box is checked to save the settings in
your scan, then click OK.
9 Click Scan to scan your image.
10 Click File > Print Preview. Click the Show More Options box, then select
Color Management from the drop-down box. Select the printer profile you
created in step 1 for the paper you’re going to print on.
11 Click Print, check your settings in your printer software (making sure that
color management is turned off and all the settings are the same as you set
them when creating your printer profile with MonacoEZcolor), close your
printer software, and then click OK to print your image.
Note: See your electronic SilverFast manual and movies on the SilverFast
CD-ROM for detailed color space and color management information. To view the
manual and movies, you’ll need Adobe Acrobat Reader and QuickTime 6.0 or
later. Acrobat Reader is included on your CD-ROM.
Scanning 48-bit Images
To obtain images in the full 48-bit color depth that your scanner offers, you can
scan into ArcSoft PhotoStudio
®
with EPSON Scan. You can also scan an image
with the stand-alone SilverFast application.
1 Raise the scanner lid and place your photo face down on the glass. Make
sure the document mat is in place on the scanner lid.
2 In Windows or Mac OS 9.x, use Acquire in
PhotoStudio with Epson Perfection 4870
selected as the source.
In Mac OS X, open the stand-alone
SilverFast application (SF-App) and
scan a 48-bit file. Open the image in
PhotoStudio for editing.
Note: If you have the full version of
Photoshop (6.0 or later), you can scan
48-bit images directly with SilverFast or
EPSON Scan.
More Scanning Options
Here are more ways to get the most out of your scanner and software:
• Use the SilverFast Ai Job Manager for high-capacity batch scanning.
• Organize all your photos into albums which you can easily archive to CD or
display in slideshows using ArcSoft PhotoBase.
™
• Stitch individual photos into wide panoramas or tall views with ArcSoft
PanoramaMaker.
™
• Create unique artistic creations or effects with your scanned images using
Photoshop Elements or PhotoStudio.
• Scan documents and save them as files that you can edit with Word
®
or
other word processing applications, using ABBY
®
FineReader.
®
See your
Quick Guide booklet or the ABBYY FineReader User’s Guide or Help for
instructions.
Problems?
First, check the indicator light on the scanner.
If your problem is listed here, try these suggestions.
Questions?
Here’s where to look for answers:
Quick Guide
See your Quick Guide for instructions on using DIGITAL ICE Technology,
scanning film and text, and basic troubleshooting.
On-Screen Reference Guide
Double-click the Perfection 4870 Reference Guide icon on your desktop.
If you didn’t install it, insert the scanner software CD-ROM in the CD-ROM or
DVD drive. At the Custom Installation screen, select Scanner Reference Guide
only, then click Install. You must have Microsoft
®
Internet Explorer, Netscape
®
Navigator (versions 5.0 or later), or Apple
®
Safari
™
(version 1.0 or later) to
read the Reference Guide.
On-Screen Help for EPSON Scan
Click the Help button or question mark that appears on the screen when you’re
using these programs.
EPSON Technical Support
EPSON provides technical assistance 24 hours a day through the electronic
support services and automated telephone services described below:
• World Wide Web
From the Internet, you can reach EPSON Support at
http://support.epson.com.
• Automated Telephone Services
To use Automated Telephone Services, you must have a touch tone
telephone and call (800) 922-8911. Your EPSON SoundAdvice Express
Code is 70490. Use it to quickly select your scanner in SoundAdvice.
• To Speak to a Customer Service Representative
Dial (562) 276-4382 (U.S.) or (905) 709-3839 (Canada), 6
AM to 6 PM,
Pacific Time, Monday to Friday. Toll or long distance charges may apply.
Before you call, please have the following information ready:
• Product name (EPSON Perfection 4870 Pro)
• Product serial number (located on the back of the scanner)
• Proof of purchase (such as a store receipt) and date of purchase
• Computer configuration
• Description of the problem
Software Technical Support
* Toll or long distance charges may apply.
EPSON is a registered trademark of SEIKO EPSON CORPORATION. EPSON Perfection is a registered trademark
and SoundAdvice is a service mark of Epson America, Inc.
DIGITAL ICE is a trademark of Kodak.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their
respective owners. EPSON disclaims any and all rights in those marks.
© 2003 Epson America, Inc. 11/03
CPD-16660
Printed in Singapore XXXXXX XX.XX-XX
Before and After DIGITAL ICE for Photo Print
Before and After Color Restoration Before and After Dust Removal
Flashing green Warming up or scanning.
Green Ready to scan.
Flashing red Make sure both transportation locks are unlocked.
Try restarting your computer and turning the
scanner off and then on again.
If the red light is still flashing, contact your dealer or
EPSON.
Off Make sure the scanner is connected to your
computer and turned on.
The New Hardware Wizard
appears on your screen.
Click Cancel and follow the steps in “Install the
Software” on the other side of this sheet.
Disconnect the scanner before installing the
software.
The scanner makes a
grinding noise when it is
turned on.
Make sure both transportation locks are unlocked.
You see a message about
a HI-SPEED USB device
in Windows XP.
Click the x in the corner of the message to close it.
Your scanner will work correctly.
You see an error message
when you try to scan, or
the scanner doesn’t scan.
Make sure the scanner is connected to your
computer, plugged into a power source, and the
power switch is turned on.
Make sure both transportation locks are unlocked.
Software Telephone*/Fax* Internet and E-mail
EPSON Scan U.S.: (562) 276-4382
Canada: (905) 709-3839
6:00
AM to 6:00 PM, Pacific
Time, Monday to Friday
support.epson.com
ABBYY FineReader
Sprint
(510) 226-6719
fax: (510) 226-6069
www.abbyyusa.com
support@abbyyusa.com
Adobe Photoshop
Elements
(206) 675-6126
6:00
AM to 5:00 PM, Pacific
Time, Monday to Friday
(pay support)
www.adobe.com/support
techdocs@adobe.com
ArcSoft application
software
(510) 440-9901
8:30
AM to 5:30 PM, Pacific
Time, Monday to Friday
www.arcsoft.com/
techmain.htm
support@arcsoft.com
LaserSoft Imaging
TM
SilverFast
(941) 383-7496
9:00
AM to 5:30 PM, Eastern
Time, Monday to Friday
(pay support)
fax: (941) 387-7574
www.SilverFast.com
support@SilverFast.com
Monaco Systems
TM
MonacoEZcolor
(978) 749-9944
9:00
AM to 5:00 PM, Eastern
Time, Monday to Friday
www.monacosys.com/
support.html
support@monacosys.com
SM
