Epson PLQ-20 Setup Guide

Epson PLQ-20
20 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #2 background imageLoading...
Page #2 background image
2
R4C7290_UK
Setup Guide Rev. D
7290U.TOC A5 size
6/11/04
L
Proof Sign-off:
ABE J. Hashimoto, K.Takehara
T.Takahashi
ABE S.Halvorson
Contents
Introduction
Where to Find More Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
FCC Compliance Statement for United States Users . . . . . . . . . . . . 3
WARNING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 1 Setting up the Printer
Unpacking the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remove the protective materials. . . . . . . . . . . . . . . . . . . . . . . . . 6
Assembling the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the Printer to Your Computer. . . . . . . . . . . . . . . . . . . . 11
Connecting the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Plugging in the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 2 Safety Instructions
Warnings, Cautions, and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Hot Parts Caution Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Other manuals for Epson PLQ-20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson PLQ-20 and is the answer not in the manual?

Epson PLQ-20 Specifications

General IconGeneral
ColorYes
Character setsISO 8859-15, PC437, PC850, PC858
Character pitch10, 12 cpi
Built-in barcodesCODABAR (NW-7), EAN13, EAN8, Industrial 2/5, Interleaved 2/5, UPC-A, UPC-E
Maximum number of copies7 copies
Maximum print speed (LQ)144 cps
Maximum print speed (draft)432 cps
Maximum printing width (columns)94
Needles24
Fonts includedPR2: 4LQ & 2 Draft Bitmap, 8 Barcode, ESC/P: 9LQ & 1 Draft Bitmap, 4 Scalable typefaces, 8 Barcode
Print technologyDot matrix
Connectivity technologyWired
Print directionBi-directional
Ribbon life (black, LQ)5 million characters
Ribbon life (black, draft)10 million characters
Mean time between failures (MTBF)10000 h
Standard interfacesParallel, RS-232, USB 2.0
Certification73/23 EEC, EN60950, EN55022 (CISPR pub.22) class B, AS/NZS 3548 class B, EN55022 class B, EN61000-3-2, EN61000-3-3, EN55024
Product colorGray
Country of originIndonesia
Page description languagesEpson ESC/P2, PPDS
Sound pressure level (printing)53 dB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)8 W
Power consumption (typical)60 W
Windows operating systems supportedWindows 2000, Windows 7, Windows 8, Windows Vista, Windows XP
Paper tray media typesEnvelopes
Pallet width1200 mm
Pallet height1000 mm
Pallet length (UK)2040 mm
Quantity per pallet28 pc(s)
Quantity per pallet (UK)42 pc(s)
Quantity per pallet layer4 pc(s)
Harmonized System (HS) code84433210
Quantity per pallet layer (UK)6 pc(s)
Package depth460 mm
Package width380 mm
Package height270 mm
Package weight9060 g
Quantity per pack1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth280 mm
Width384 mm
Height203 mm
