MS : Metallic Silver
CL : Cleaning Cartridge/Cleaning Ink Supply
Unit
SC-S60600 Series/SC-S60600L Series/SC-S40600
Series
BK : Black
Y : Yellow
M:Magenta
C:Cyan
F Waste Ink Bottle status
Displays the approximate amount of space available
in the Waste Ink Bottle. The display changes as
shown below when the waste ink bottle is nearly full
or an error occurs.
Normal Warning or error
1 Status indicators
The status of the Waste Ink Bottle is shown as
follows.
: No error. The indicator changes to
show the amount of space available.
: The Waste Ink Bottle is almost full.
Ready a new Waste Ink Bottle.
: The Waste Ink Bottle is full. Replace
with a new Waste Ink Bottle.
G Wiper unit status
Displays the remaining amount for the wiper.
: The indicator decreases according to the
amount remaining.
H Additional Print Drying System status
Displays the settings for the Additional Print Drying
System (optional for the SC-S80600 Series/
SC-S80600L Series/SC-S40600 Series).
No icon : Not installed, or it is not installed
correctly.
: The drying fan is enabled.
: The drying fan is not enabled. To start
the fan, select Additional Dryer for
ON in the setup menu.
U “Changing the Heater Temperature and Drying
Settings” on page 55
Note:
You can check E to G in a little more detail from Level
on the setup menu.
U “The Printer Status Menu” on page 113
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Introduction
18
