c
Important:
❏ If the roll holder screw is loose, the roll
holder may move during printing. This
could cause stripes and unevenness in the
print results.
❏ If the right and left edges of the roll are not
aligned, realign them.
N
Rotate the handle until part A in the illustration
below is fully inserted.
c
Important:
Once part A is hidden, do not turn the handle
any further. Failure to observe this precaution
could damage the roll holder.
If part A is still visible even after the handle has
been turned fully, rewind the handle. Loosen
the roll holder screw on the right side, and then
restart from Step 4.
O
Insert the media approximately 30 cm into the
opening, then lower the media loading lever.
P
Confirm that the left edge of the media is within
the range of the label's rectangle, as shown in the
illustration below.
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Basic Operations
34
