Note:
If the left edge of the media is not within the black
square of the label, do steps 5 to 16 in reverse to
adjust the position of the roll holder. Do not
attempt to reposition the roll holders while they are
inserted in the media.
Q
R
Hold the center of the media in one hand, and
pull it straight until it is aligned with the bottom
edge of the label on the after heater.
Do not pull the media with both hands. This
could cause the media to skew or move around.
S
T
Tap lightly on both ends of the media, and check
if there is a difference in tension between the left
and right sides.
If there is a difference in tension, the media
becomes loose.
From the front of the printer, raise the media
loading lever, and correct the looseness in the
media.
Once the looseness is corrected, lower the media
loading lever.
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Basic Operations
35
