B
While pulling the paper tape straight down, wrap
it around the roll core from back to front, and
affix it using commercially available adhesive
tape.
c
Important:
Attach the media to the take up roll core with
the media in a taut state. If media is attached
in a loose state, the media may move around
during take-up.
C
Flip the Auto switch to .
D
Lower the tension bar until it slightly touches the
paper tape.
When there is no paper tape
A
While pulling the center of the media straight
down, wrap it around the roll core from back to
front, and affix it using commercially available
adhesive tape.
c
Important:
Attach the media to the take up roll core with
the media in a taut state. If media is attached
in a loose state, the media may move around
during take-up.
SC-S80600 Series/SC-S80600L Series/SC-S60600 Series/SC-S60600L Series/SC-S40600 Series User's Guide
Basic Operations
42
