Appendix Connector Summary 34
Epson Stylus NX125/T13/NX130 series Revision F
4.2 Connector Summary
Cable connections of this printer are shown below.
Figure 4-1. Connector Summary
B
M
Y
C
PS Board
Panel Board
Panel Board
J301
J3 J2
J5
J8
J7 J11 J10
J9
J4
Scanner Unit
Panel Unit
J601
CIS Module
J201
J201
PF Motor
Main Board
PF Encoder
Scanner Motor
Printhead
CR Contact Module
CR Encoder
CR Motor
AC in
CSIC
Only NX125 series
Panel Unit
T13 series
NX125 series
