12 | Attaching the Paper Basket
11. Insert a nut into the center bolt hole on the basket holder, and align the right-hand basket arm with
the bolt hole.
12. Insert the BOLT CHANNEL through the basket arm and into the bolt hole. Insert the bolt into the
BOLT CHANNEL and tighten it. Repeat steps 11 and 12 on the left side of the printer.
13. Attach the shorter arm to the inside of the basket holder on the left side of the printer. Use two nuts to
hold the arm in place.
