Attaching the Paper Basket | 9
2. Insert a plastic connector into the end of one of the shorter square poles.
3. Slide the pole through the holes in the STABILIZERS and attach the other plastic connector to the
end of the pole. Then, fasten the plastic connectors in place on each side of the stand as shown.
4. Attach the stack guides to the bottom of the printer. Make sure each guide snaps securely into place.
