Epson TM-T20 User Manual

TM-T20 User’s Manual 11
English
Hanging the Printer on a Wall
To hang the printer on the wall, follow the steps below.
CAUTION:
To fix the printer securely, install the wall hanging bracket on a wall made of
wood, concrete, or metal. The thickness of the wall should be 10 mm {0.4”} or
more.
Be sure to use metallic screws.
The screws on the wall side must have a pull-out strength of 150 N (15.3 kgf) or
more.
1. Install 2 screws (screw diameter: 4 mm {0.16"}, head diameter: 7 to 9 mm {0.28
to 0.35"}) in the wall at an interval of 80 mm {3.15"}. Make sure the length of
the screw’s body in the wall is 10 mm {0.39"} or more, and the length outside
the wall is 3 to 4 mm {0.12 to 0.16"}.
2. Remove the installed 2 screws from the printer, as shown in the illustration
below.
3. Install the wall hanging bracket on the printer, and fix it using the screws
removed in Step 2.
80 mm
4 mm
3~ 4 mm
7~ 9 mm
10 mm or more
Screws
Wall hanging
bracket

Epson TM-T20 Specifications

General

Autocutter	Yes
Print Method	Line thermal
Paper Width	79.5 ±0.5 mm
Interface	USB, Ethernet
Dimensions	140‎ x 199 x 146 mm (Width x Depth x Height)
Power Supply	External power supply
Paper Thickness	0.06 - 0.085 mm
