Epson TM-T70-i User Manual

iv
English
Specifications
*1: The USB connector is only for the optional product, and the Micro-USB connector is for setting. The
analog RGB connector is not available currently.
*2: Be sure to use the included dedicated AC adapter.
Printing method Thermal line printing
Printing width 72.2 mm {2.84"}, 512 dot positions
Roll Paper (single-ply) Size: 79.5 mm ± 0.5 mm {3.13" ± 0.02"}
Maximum outside diameter: 83 mm {3.27"}
Roll Paper spool diameter:
Inside: 12 mm {0.47"};Outside: 18 mm {0.71"}
Thermal paper type Specified: NTP080-80
Interface*
1
Ethernet (10/100Base-T/TX), USB (Compliance: USB 2.0),
Micro-USB (Compliance: USB 2.0), Analog RGB (VGA)
Power supply
(Dedicated AC adapter)*
2
EPSON AC ADAPTER,RA Model: M266A (DC 24V/DC 5V)
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: –10 to 50°C {14 to 122°F}, except for paper
Humidity Operating: 10 to 90% RH
Storage: 10 to 90% RH, except for paper
Overall dimensions 114 × 125 × 194 mm {4.49 × 4.92 × 7.64"} (H × W × D)
Weight (mass) Approx. 1.8 kg {3.96 lb} (Roll paper exclosed)

Epson TM-T70-i Specifications

General

Type	POS printer
Character size	1.69 x 3.38 mm
Print technology	Thermal
Wi-Fi	No
Ethernet LAN	Yes
Ethernet LAN data rates	10, 100 Mbit/s
USB connector	Micro-USB, USB Type-A
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Connectivity technology	Wired
Mean cycles between failures (MCBF)	52000000
Internal memory	256 MB
Autocutter durability	1.5 million cuts
Mean time between failures (MTBF)	360000 h
Voltage	24 V
Product color	Black

Weight and Dimensions

Depth	194 mm
Width	125 mm
Height	114 mm
